Market-Leading Compressed Air Hose
Mantex combines lightweight and flexibility with the highest pressure ratings and safety. The hose is designed for high burst pressure compressed air applications and is highly resistant to abrasion and kinking. Nitrile rubber and PVC are blended together to create a high-quality hose with a UV barrier to prevent UV damage.
Made to Perform
Mantex is designed to be your ideal rubber hose for compressed air applications, but the hose can also be used for other applications such as transporting liquids. For your convenience, the hose has been designed to be easy to coil for storage and transportation.
Explore Mantex
Mantex
Mantex
Product Specifications
Primary Uses & Applications
- Compressed Air for Powertools and Machinery
- Snow Production
- Transport of Liquids
Color Options
- Black (standard)
- Yellow (optional)
Lengths and Diameters
We offer a range of diameters and lengths for this hose, depending on the version. The diameters range from 20mm to 76mm, and for some diameters, the hose can be delivered in lengths up to 200m.
Operating Temperature
The hose has been developed to perform in different weather and environments, with an operating temperature from -30°C to +75°C ( -22°F to +167°F). Intermittent use up to +80°C (+176°F).
Mantex
| INTERNAL DIAMETER WALL | WALL THICKNESS | WEIGHT | BURST PRESSURE | TENSILE STRENGTH | |||||
| Inch | mm | Inch | mm | Lbs / Ft | Kg / m | Psi | Bar | x 1000 Lbs | Tons |
| 3/4 | 20.0 + 1.6 | 0.09 | 2.3 | 0.14 | 0.21 | 1450 | 100 | 4.2 | 1.9 |
| 1 | 25.4 + 1.6 | 0.10 | 2.5 | 0.18 | 0.27 | 1450 | 100 | 5.1 | 2.3 |
| 1 1/2 | 38.0 + 1.6 | 0.10 | 2.5 | 0.25 | 0.38 | 1235 | 85 | 7.7 | 3.5 |
| 2 | 51.0 + 2.0 | 0.10 | 2.5 | 0.35 | 0.53 | 870 | 60 | 10.4 | 4.7 |
| 2 1/2 | 65.0 + 2.0 | 0.11 | 2.9 | 0.45 | 0.68 | 725 | 50 | 14.8 | 6.7 |
| 3 | 76.0 + 2.0 | 0.12 | 3.1 | 0.63 | 0.95 | 725 | 50 | 17.9 | 8.1 |
- Note: Safety factor bp/wp is 4:1 (25%) for compressed air. (ISO7751)
Construction Catalog
Want more in-depth knowledge about how our hoses can be used for construction? We got you covered in our construction catalog.
Mining Catalog
Want more in-depth knowledge about our lay-flat hoses for water management systems? Well, we got you covered in our mining catalog.
